Tool
9836 3123 01 161 (428)
Click Create QRTT to create the Psets and
Multistages needed. The target torque and
angle is then set by the ACTA 4000 before
the start of each calibration.
The tool calibration is started by a command
from the ACTA 4000 or by pressing the tool
trigger depending on if the tool is configured
for remote start or not. The result of a
calibration is displayed as a normal
tightening. When a calibration batch is
completed, event code E710 ACTA/QRTT
calibration is displayed and stored in the event
log of the Power Focus.
It is necessary for the Power Focus to have enough memory space available to store the Multistages and
Psets needed. If the calibration shows an unsatisfactory result the operator is assumed to take the
appropriate action. No calibration value (calibration- or normalization value etc.) is changed
automatically.
11.4.5 Motor tuning
Motor tuning adjusts the tool and motor control unit. Sync motor tuning feature is only available from the
Sync reference of a configured Sync group with between two and ten Sync members. The Sync motor
tuning process starts simultaneously for all Sync members when pressing the tool trigger of the Sync
reference. For information about the Sync functionality, see section Sync.
It is important that no torque is applied to the socket of the tool when it is subject to any
kind of motor tuning. Make sure that the socket is able to rotate freely.
