Atlas Copco Power Focus 3000 User Manual

Fieldbus
9836 3123 01 201 (428)
The screenshot below displays available parameters for fieldbus type DeviceNet. Click Store to save the
settings.
15.1.1 Parameters in General setup
The table below shows parameters available for all fieldbus types. For an explanation of the parameters,
see parameter list section Fieldbus.
Parameter
Device-Net
ProfiBus-DP
Inter-Bus
ModBus Plus
Control-Net
ModBus/ TCP
Ethernet/IP
Inter-Bus 2MB
Profinet-IO
FL-Net
CC-link
F100 Fieldbus type
X
X
X
X
X
X
X
X
X
X
X
F102 From PF data length
X
X
X
X
X
X
X
X
X
X
X
F103 To PF data length
X
X
X
X
X
X
X
X
X
X
X
F104 From PF global data length
X
F105 To PF global data length
X
F106 From PF Data Offset
X
F107 To PF Data Offset
X
F110 Set node address and baud rate from
X
X
F111 FB node address
X
F112 Baud rate
X
X
