Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
328 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
16 – 200
bits
CSCI
Max 25 char
Wear
indicator
Active until service is performed (i.e. while wear alarm is pending)
X
X
X
X
21.2 Digital input and fieldbus items to PF
This section contains a description of the items that can be selected when data to the Power Focus is
configured.
For fieldbus: Set signal = a signal to set a bit/byte/bytes in the PLC. Reset signal = a signal to reset a
bit/byte/bytes in the PLC.
Description
Fieldbus items
Digital inputs
Name
Description
String
length
Data type
Value
Set signal
/Reset signal
Internal I/O
I/O Expander
ST GPIO
Function button (optional)
Abort Job
Aborts the running Job. Job
status is Job aborted.
1 bit
0 = Not used
1 = Abort
Abort Job /no
signal
X
X
X
X
8 bit (1
byte)
Character
A = Abort
Abort Job and
status
Abort Job And Reset all result
status
1 bit
0 = Not used
1 = Abort
Abort job and
status /no signal
Ack error message
Acknowledge event/error
message.
1 bit
0 = Not Used
1 = Ack Error
Ack event
message /no
signal
X
X
X
X
