Parameter list
9836 3123 01 371 (428)
Operational mode when IRC-W is used. Ad-hoc or Infrastructure
Radio channel when IRC-W is used. Valid channels: Auto, 1-14, 36, 40,
44, 48
22.5.3 Diagnostic
The tool parameters are visible depending on which tool is connected. For STB, most parameters are
invisible when the tool is offline.
Sensor tracking monitors the torque and angle sensors in real-time. A window with torque,
angle and zero offset values updates continuously. Sensor status is monitored while the
spindle is rotated (manually) or if the tool is heated/cooled etc. The motor does not run. An
exit-button ends the command and returns the user to the main diagnostic window.
Sensor tracking function is not possible to use during a tightening.
For DS tools have torque and zero offset tracking no validity since they
have no transducer. The value presented is therefore set to zero (0).
Diagnostics for tool LED's and buttons.
Diagnostics for tool LED's and buttons.
Diagnostics for tool LED's and buttons.
Diagnostics for tool LED's and buttons.
Shows the current motor temperature.
Temperature when the motor is considered overheated.
Number of times the motor has reached its temperature limit.
Maximum measured motor temperature.
22.5.4 Maintenance
The tool parameters are visible depending on which tool is connected. For STB, most parameters are
invisible when the tool is offline.
Shows the calibration value stored in the tool.
Shows the date of latest calibration for the tool. Automatically updated when
the calibration value is set.
