Parameter list
346 (428) 9836 3123 01
Maximum torque during positioning. Default value is tool dependent and
stored in tool memory. The max value is limited to T424 Max torque
positioning limit.
The limit must be lower than the maximum torque in reverse
specified by the open end gear supplier. Using higher values
can result in damaging the open end gear.
Tool
dependent,
5% of Tool
max tq
Torque search limit for snug detection
Tool
dependent,
Tool max tq
Defines how many degrees before the Snug point the start value of the PVT
compensation torque shall be used.
The angle interval after the PVT distance point, during which the PVT
compensate torque is evaluated.
Option to choose between an average value and peak value during the PVT
interval.
Delay monitoring
after cycle start
During this interval all Snug Gradients found will be disregarded. The delay
interval starts when Cycle start has been passed.
The lowest torque value allowed while searching after Snug point.
The highest torque value allowed while searching after Snug point
22.1.2 Programming +
This function is not applicable for DS tools.
Activates the current monitoring function.
The spindle torque is proportional to the motor current. By measuring motor
current a method of measurement that is independent of the torque transducer
is achieved. The torque forming current is expressed as percentage of
nominal current at T102 Tool max torque. Set an acceptance window for the
torque as redundant process control via parameters P201 CM min and P202
CM max.
Defines min limit for OK tightening.
