Parameter list
360 (428) 9836 3123 01
Result of non-
tightenings
Yes/No
Yes: The non-tightening events; OK loosening, batch increment or batch
decrement, and not performed tightenings due to digital inputs, Bypass
Pset in Job or Abort Job, generate a result that is stored in the PF database.
No: No non-tightening results for Job are stored in the Power Focus
database. If this parameter is set to Yes, parameter C211 for Pset and
Multistage is disregarded in Job.
Reset all identifiers
at Job done
If activated, a reset will be made for all identifiers (Type 1, Type 2, Type 3
and Type 4) at Job done.
Select whether running Pset name, Job name or PF name shall be
displayed in the header of result view (PF Graph display).
22.4 Controller
22.4.1 Information
The version number of the Power Focus software release (i.e. the full software package).
The version number of the application code.
The version of the parameter-tree.
The version number of the RBU-code.
The version number of the Boot-code.
The version number of the DSP-code.
The version number of the MC-code.
The type of the Power Focus.
The serial number of the Power Focus unit. It is possible to change the number.
The type of RBU (Rapid Backup Unit) inserted in the Power Focus. The available RBU
types are; Bronze, Silver, Gold, DS, X or a Customer special.
The serial number of the RBU (the hard-coded, unique, MAC-address).
Shows the drive size of the controller. Available drive sizes are:
SL, Small, Medium, Large, Uni, IRC.
