Atlas Copco Power Focus 3000 User Manual

Controller
9836 3123 01 119 (428)
9.2 Job configuration
9.2.1 Creating a Job group
The PF units in a Job group must be working in the same Cell. Therefore, before creating Job groups a
Cell has to be configured (see section Controller for more information).
After cell configuration, the next step is to create a Job group including Job reference and Job client.
In the PF Map, select Controller > Network.
To define a Job reference, set the parameter C316 Job reference IP address equal to the parameter C300 IP
address of the same controller.
To define a Job client, set the C316 Job reference IP to the C300 IP address of the Job reference controller.
Click Store to save the settings and reboot PF.
Job reference settings
Job member
settings
