Atlas Copco Power Focus 3000 User Manual

Introduction
9836 3123 01 15 (428)
2 Introduction
This manual describes the Power Focus (PF) controller and how to configure it using ToolsTalk PF.
 The first sections describe PF with hardware and software accessories, how to connect, and the user
interface.
 The main part of the user guide describes how to use the ToolsTalk PF software to configure PF.
 The last part of the user guide lists the parameters and event codes used in PF.
2.1 Revision history
Apart from editorial updates, this manual has been revised as follows.
 Updates to reflect functional changes: Contact Atlas Copco for a release description for the current
release.
2.2 Abbreviations
Abbreviation
Description
R
The center line
X
The mean
X
The mean of the average
<= =>
Arrow (button)

Sigma (standard deviation)
α
Alpha (often a symbol for angle)
µ
Mu (the values of the mean)
%
Percent
A
Ampere
AC
Alternating Current
ACK
Acknowledged
Admin
Administration
Ang con
Angle control
Ang mon
Angle monitoring
bits/s
Bits per second
Abbreviation
Description
CAN
Controller Area Network
CC
Control Card
CCW
Counter-Clockwise
CD
Compact Disc
Ch
Channel
CL
Clear (button)
Config
Configuration
CW
Clockwise
DC
Direct Current
Deg
Degrees
Deg C
Degrees centigrade
DigIn
Digital Input
DigOut
Digital Output (relay)
DSP
Digital Signal Processor
ft.lb
Foot-pound
GFI
Ground Fault Interrupter
HW
Hardware
