Make settings for Open Protocol, Tools
Talk and the Acta port.
If used, activate and setup ToolsNet.
Click Store to save settings.
The Power Focus software offers extended networking possibilities. The Cell and Net concepts are part
of the RBU Gold and RBU Silver types.
Ethernet TCP/IP networking makes it simple to program and overview all PF units in the network from
a PC with ToolsTalk PF software installed. All data traffic from Power Focus could also be collected
and compiled by ToolsNet.
Via the Cell concept, it is possible to arrange all PF units at an assembly station in a group, giving extra
functionality to the work station. The Net concept enables functionality to group all cells on the
assembly line into one net.
The figure below illustrates a cell consisting of four PF Graph controllers and a switch.
