Fieldbus

220 (428) 9836 3123 01

Function

Dip switch

AD0

AD1

AD2

AD3

AD4

AD5

BD2

BD1

Baud rate (bit/sec)

Dip 1 - 2

125k

250k

500k

Reserve (SW-setting)

Address

Dip 3 – 8

000 000

000 001

000 010

000 011

…

111 110

111 111

Mac ID (node address)

To set the Mac ID from ToolsTalk PF all DIP switches must be set to “On” (11 111 111).

The Mac ID cannot be changed when the power is switched on.
