Atlas Copco Power Focus 3000 User Manual

Fieldbus
230 (428) 9836 3123 01
Node address
Node address is set with the first DIP switch on the fieldbus module, allowing address settings from 1-64
in binary format. If the set node address is from SW1, ModBusPlus takes SW node address regardless of
hardware switch position.
1 (MSB)
2
3
4
5
6 (LSB)
Function
ON
ON
ON
ON
ON
ON
Node address set to 1
ON
ON
ON
ON
ON
OFF
Node address set to 2
ON
ON
ON
ON
OFF
ON
Node address set to 3
-
-
-
-
-
-
-
OFF
OFF
OFF
OFF
OFF
ON
Node address set to 63
OFF
OFF
OFF
OFF
OFF
OFF
Node address set to 64
The Node address cannot be changed during operation.
Source address
Source address is set using the second dip switch (the one close to LED) on the fieldbus module; this
enables address settings from 1-64 in binary format. If the set source address is from SW2, ModBusPlus
takes SW source address regardless of hardware switch position.
1 (MSB)
2
3
4
5
6 (LSB)
Function
ON
ON
ON
ON
ON
ON
Source address set to 1
ON
ON
ON
ON
ON
OFF
Source address set to 2
ON
ON
ON
ON
OFF
ON
Source address set to 3
-
-
-
-
-
-
-
OFF
OFF
OFF
OFF
OFF
ON
Source address set to 63
OFF
OFF
OFF
OFF
OFF
OFF
Source address set to 64
The source address cannot be changed during operation.
Icon file
It is not necessary for ModBusPlus to install a special file to recognize our product and it does not support
icon files.
