Atlas Copco Power Focus 3000 User Manual

Fieldbus
232 (428) 9836 3123 01
Ethernet/IP module
Variable
Limits
Information
IP address
Do not configure the module to use any of them
0.x.x.x
127.x.x.x
x.x.x.0
x.x.x.255
Devices on an Ethernet network are not
allowed to be configured to the IP
addresses listed in left column
ModBus/TCP data address
000h + I (I = 0, 1, …) From PF*
400h + I (I = 0, 1, …) To PF*
This address is based on words.
0000h + I (I = 0, 1, …) From PF*
4000h + I (I = 0, 1, …) To PF*
This address is based on bits
EtherNetIP Assembly Instance
0
Input (Producing Instance): 100 (64h),
Output (Consuming Instance): 150 (96h),
Configuration Data Instance /size = 0/: 197 (C5h),
Input-Only (Heartbeat): 198 (C6h),
Listen-Only (Heartbeat): 199 (C7h)
This is used to configure and transfer
data to/from EtherNetIP module
For Anybus FW >1.32 (For FW > 2.00
and TTPF SW > 10.8 when Assembly
instance parameter F157 is 0)
EtherNetIP Assembly Instance
1
Input (Producing Instance): 100 (64h),
Output (Consuming Instance): 150 (96h),
Configuration Data Instance /size = 0/: 5 (05h),
Input-Only (Heartbeat): 3 (03h),
Listen-Only (Heartbeat): 4 (04h)
This is used to configure and transfer
data to/from EtherNetIP module
For Anybus FW <1.33 (For FW > 2.00
and TTPF SW > 10.8 when Assembly
instance parameter F157 is 1)
Data to PF total length
0 - 200 bytes*
Must be the same in PF and PLC.
Data from PF total length
0 - 200 bytes*
Must be the same in PF and PLC.
* The data length is in PF limited to 200 bytes. ModBus/TCP and Ethernet/IP standard allows 1024 bytes data
Fieldbus connectors
The module uses standard Ethernet connector RJ45.
The module uses twisted-pair cables, and no external termination is required.
RJ45 (Standard)
Pin
Signal
1
TD+
2
TD-
3
RD+
4
Termination
5
Termination
6
RD-
7
Termination
8
Termination
