Introduction to Power Focus
24 (428) 9836 3123 01
ST scanner is placed on the tool and works as a barcode reader. For more information
about the function of identifiers, see section Identifier.
GPIO (General purpose I/O) is a digital input and output connector. The four buttons
combined with four LED’s can each be configured as a digital input and/or digital
output.
ST selector has two different modes, mode 1 and mode 2. In Mode 1, the selector only
utilizes the tool accessory bus as GPIO. This mode only supports a maximum of 15 Psets
(1-15). In Mode 2, the selector takes full advantage of the bus capabilities.
For more information about the ST selector, see section ST-selector connection.
TLS ST Tag is an external positioning unit for positioning of the tool in the surroundings.
The unit also has a 7-color LCD indicator for sending status messages to the operator.
