Atlas Copco Power Focus 3000 User Manual

Monitors
264 (428) 9836 3123 01
Part
Description
PF name
Name of PF
Pset
Pset used to perform the tightening
VIN
Vehicle Identification Number
Overall status
Indicator for the overall status of the tightening
Final torque
Final torque of the tightening
Final torque status
Status-indicator for final torque.
(yellow-low/ green-OK/red-high)
Final angle
The final angle of the tightening
Final angle status
Status-indicator for the final angle.
(yellow-low/ green-OK/red-high)
Batch
The order of the current operation in the batch
Batch order
The overall status of the respective operation in the batch
Plot chart
Displays the final torque and final angle, relative to the acceptance window
Torque chart
Displays the torque as a function of time
Events
Warnings and events
