Parameter list
9836 3123 01 363 (428)
Defines the IP address to the Power Focus acting Job reference.
The Job reference monitors and collects information from the Job members
included in the group. RBU dependent.
This IP address must be written into each included Job member.
Defines the IP address to the Power Focus acting Sync reference.
The Sync reference monitors and collects information from the Sync members
included in the group. RBU dependent.
This IP address must be written into each included Sync member.
On/Off. Enable/disable Multicast functionality.
It is possible to set this IP address between 224.0.0.1 (all devices on this sub
net) and 239.255.255.255 (multicast standard).
Only valid if C320 Multicast is activated.
Port number for multicast communication.
None/All/Not ok
The results that are reported to the multicast address.
None/All/Not ok
The traces that are reported to the multicast address.
On/Off. Used if sending Sync status on multicast.
On/Off. Used if sending event code on multicast.
Port number for open protocol server Ethernet communication.
Serial cable loss
detection
When enabled, Power Focus detects cable loss when running open protocol
serial on serial port 1 or 2.
Port number for ToolsTalk PF Ethernet communication.
On/Off
Result after each tightening is recorded in ToolsNet. A ToolsNet database
registers and stores the results from tightenings, traces, data and history. Each
PF units can store information from approximately 5000 tightenings. But the
capacity in the ToolsNet database is, in principle, unlimited. The information
can be mapped against the Power Focus, object or VIN-number, as desired.
IP address for ToolsNet server. Only valid if C350 ToolsNet is activated.
Port number for ToolsNet communication.
Port 6570 is not to ToolsNet but to the PIM server which connects
PF units to ToolsNet.
None/All/Not ok
The traces reported to ToolsNet.
