Atlas Copco Power Focus 3000 User Manual

Event codes
9836 3123 01 417 (428)
ACTA/QRTT calibration information
When an ACTA/QRTT calibration batch is completed, event code E710 ACTA/QRTT calibration is
displayed.
Torque result bits show the result of the torque calibration. All bits are sent as an unsigned 16 bit integer.
Angle result bits show the result of the angle calibration. All bits are sent as an unsigned 16 bit integer.
First integer
Second integer
Third integer
Fourth integer
Torque result bits
Angle result bits
Dec
Event
Dec
Event
Not used
Channel number.
1
Batch result torque OK.
1
Batch result angle OK.
2
Torque min failed.
2
Angle min failed.
4
Torque max failed.
4
Angle max failed.
8
Torque LCLx failed.
8
Angle LCLx failed.
16
Torque UCLx failed.
16
Angle UCLx failed.
32
Torque LCLr failed.
32
Angle LCLr failed.
64
Torque UCLr failed.
64
Angle UCLr failed.
128
Torque CP > failed.
128
Angle CP > failed.
512
Torque CPK > failed.
256
Angle CPK > failed.
1024
Torque CAM > failed.
512
Angle CAM > failed.
2048
T Diff < failed.
