PF user interface
42 (428) 9836 3123 01
Indicators
The OK light indicates when the result of the tightening is within the specified limits. The indicator
remains active until the next cycle starts.
OK flash light indicates that it is safe to disconnect the tool. The LED goes off when the tool is
disconnected.
The n x OK light indicates when the number of approved tightenings corresponds to the number (batch
size) programmed into PF. The indicator remains active until the next cycle starts.
The NOK red light indicates when at least one result of the tightening falls outside the specified limits.
The light is active until the next cycle starts. NOK flashing red indicates that it is NOT safe to disconnect
the tool. The LED goes off after three seconds.
The JOB OK light indicates when the result of the Job is finished. The light remains active until the next
cycle starts or when the system is reset.
The ALARM indicates that an alarm message needs to be acknowledged. The light is active until the
message is cleared. The alarm light can also flash indicating an active alarm that does not need to be
acknowledged, i.e. service indicator alarm.
The STAT light indicates when the calculated values fall outside statistical control limits. The light
remains active until the values are within the control limits or the memory has been reset.
The Auto set light indicates when the Auto set programming function is active. The light goes off when
Auto set is finished.
PROG. CONTROL
(padlock symbol)
If PF is in programming mode the Programming control light (illustrated by an open padlock) flashes
green. Programming control can be undertaken via the unit itself, via another PF Graph or via ToolsTalk
PF. A steady green light indicates that the programming keys on the front panel are unlocked.
Soft keys and keypad
Each soft key is used to select an option or a menu block from the display.
Select another controller within the configured cell.
In result mode: Select Pset to use if C200 is set to PF keyboard. In programming mode: Select Pset or
Job to configure.
Pressing the Question mark key displays information about the software, RBU type and the connected
tool.
Press the Print key to do a print-out to a connected printer.
Up and down arrows: Scroll up and down in the menus
Left arrow: Leave current option or view
Right arrow: Execute selected function, select current option or view
Select result mode. Menu block View has options for the result view.
OK is used to execute selected functions and acknowledge event.
Cancel the current operation and return to the previous view.
Numeric keypad. Press repeatedly to toggle between letters and numbers
Clear the last input letter or number.
Enter is used to activate inputs in the programming blocks
