PF user interface
9836 3123 01 53 (428)
Press the F key three times. F3/tool alternates in the display if a tool is connected. Otherwise F3/---- is displayed.
Press Enter to activate the motor tuning process. The display shows the process status during progress, (1 to 7).
Press the Tool trigger to start motor tuning. The trigger must be pressed during the entire process.
Release Tool trigger or press F to abort the motor tuning process.
When the motor tuning process ends, done (for succeeded) or Err (for failed) is displayed.
After a few seconds F3/tool starts alternating on the display.
F4/Pset alternates in the display if the C200 Pset is set to PF keyboard. Otherwise F4/---- is displayed.
Press Enter to access the available Psets. Browse existing Psets by pressing the +/- keys.
Press Enter to select a Pset and exit.
Press F to exit (no selection).
F5/batS alternates in the display, indicating that a Pset is selected. Otherwise F5/---- is displayed.
Press Enter to access the Batch Size value (range 0 - 99). Change the batch size value by pressing the +/- keys.
Press Enter to save and exit.
Press F to exit (no save).
F6/DISC alternates in the display if a tool is connected. Otherwise F6/---- is displayed.
If safe to disconnect tool is rolling on the display press Enter. The tool may now be disconnected.
If Fail is displayed, DO NOT disconnect the tool. Press F or Enter to exit.
Press the F key seven times. F7/stun alternates in the display.
Press Enter to activate the Sync motor tuning process. The display shows two numbers simultaneously during
progress. The number to the left is the percentage of Sync member that has finished motor tuning, and the
number to the right is the process status (1 to 7).
Press the Tool trigger on the Sync reference to start Sync motor tuning. The trigger must be pressed during the
entire process.
Release the Tool trigger or press the F key to abort the motor tuning process.
When the motor tuning process ends, done (for succeeded) or Err (for failed) is displayed. After a few seconds
F7/stun starts alternating on the display.
F8
Controller IP
settings
Press the F key eight times.F8/IP alternates in the display.
Press Enter. Addr is shown. Press Enter to edit the first part of the IP address. Increase/decrease the number by
pressing the Plus/Minus keys. Press Enter to confirm and edit the second part of the address. Repeat the
procedure for all remaining IP address parts.
Press Enter. Sub is shown. Press Enter to edit the first part of the subnet mask. Increase/decrease the number by
pressing the Plus/Minus keys. Press Enter to confirm and edit the second part. Repeat the procedure for all
remaining subnet parts.
Press Enter. rout is shown. Press Enter to edit the first part of the default router. Increase/decrease the number
by pressing the Plus/Minus keys. Press Enter to confirm and edit the second part. Repeat the procedure for all
remaining router parts.
Event code E857 Reboot needed before changes take effect will be blinking on the display when finished, if any
changes have been made. Press Enter to acknowledge the event.
Restart PF.
F10
Wireless tool
pairing mode
Press the F key ten times. F10/pair alternates in the display.
Press Enter to activate the pairing process. The display shows the process status during progress (1 to 5).
Event code E550 Radio contact with tool established, tool accessible is shown on the display when finished.
