Other time-processing CRBasic instructions are governed by these same rules.
Consult CRBasic Editor Help for more information on specific instructions.
8.1.2 Analog Measurements — Details
Related Topics:
• Analog Measurements — Overview (p. 63)
• Analog Measurements — Details
(p. 305)
The CR1000 measures the following sensor analog output types:
• Voltage
o Single-ended
o Differential
• Current (using a resistive shunt)
• Resistance
• Full-bridge
• Half-bridge
Sensor connection is to H/L] terminals configurable for differential (DIFF) or
single-ended (SE) inputs. For example, differential channel 1 is comprised of
terminals 1H and 1L, with 1H as high and 1L as low.
8.1.2.1 Voltage Measurements — Details
Related Topicss:
• Voltage Measurements — Specifications
• Voltage Measurements — Overview
(p. 63)
• Voltage Measurements — Details
(p. 305)
8.1.2.1.1 Voltage Measurement Mechanics
Measurement Sequence
An analog-voltage measurement, as illustrated in the figure Simplified Voltage
Measurement Sequence
(p. 306), proceeds as follows:
1. Switch
2. Settle
3. Amplify
4. Integrate
5. A to D (successive approximation)
6. Measurement scaled with multiplier and offset
7. Scaled value placed in memory
305
