Campbell CR1000 User Manual

Section 5. System Overview
5.3.2 Wiring Panel — Overview
Related Topics
• Wiring Panel — Quickstart (p. 43)
• Wiring Panel — Overview
(p. 76)
• Measurement and Control Peripherals
(p. 366)
The wiring panel of the CR1000 is the interface to most functions. These
functions are introduced in the following sections while reviewing wiring-panel
features illustrated in the figure Wiring Panel
(p. 44). The table CR1000 Terminal
Definitions
(p. 76) details the functions of the various terminals on the wiring panel.
Measurement and control peripherals expand the input and output capabilities of
the wiring panel.
Figure 27. Wiring Panel
76
