Campbell CR1000 User Manual

Section 8. Operation
ListFiles requires a minimum .csipasswd access level of 3 (read only).
Table 122. ListFiles API Command Parameters
format
Specifies the format of the response. The values html, json, and
xml are valid. If this parameter is omitted, or if the value is
html, empty, or invalid, the response is HTML.
uri
If this parameter is excluded, or if it is set to "datalogger"
(uri=dl) or an empty string (uri=), the file system will be sent
from the host CR1000.
1
1
Optionally specifies the URI to a LoggerNet datalogger station from which the file list will be
retrieved.
Examples:
http://192.168.24.106/?command=ListFiles
Response: returns the drive structure of the host CR1000 (CPU:, USR:,
CRD:, and USB:).
http://192.168.24.106/CPU/?command=ListFiles
Response: lists the files on the host CR1000 CPU: drive.
ListFiles Response
The format of the response depends on the value of the format parameter in the
command request. The response provides information for each of the files or
directories that can be reached through the CR1000 web server. The information
for each file includes the following:
Table 123. ListFiles API Command Response
path
Specifies the path to the file relative to the URL path.
is_dir
A boolean value that will identify that the object is a directory if
set to true.
size
An integer that gives the size of for a file in bytes (the value of
is_dir is false) or the bytes free for a directory.
last_write
A string associated only with files that specifies the date and
time that the file was last written.
run_now
A boolean attribute applied by the CR1000 for program files
that are marked as currently executing.
run_on_power_up
A boolean attribute applied by the CR1000 for program files
that are marked to run when the CR1000 powers up or resets.
read_only
A boolean attribute applied by the CR1000 for a file that is
marked as read-only.
paused
A boolean attribute applied by the CR1000 that is marked to run
but the program is now paused.
HTML Response
When html is entered in the ListFiles format parameter, the response will be
HTML. Following are example responses.
446

Campbell CR1000 Specifications

General

Power Requirements	9.6 to 16 VDC
Data Logger Operating System	CRBasic
Memory	4 MB
Analog Inputs	16 single-ended or 8 differential
Analog Input Resolution	13 bits
Analog Input Range	+/-2.5V
Digital I/O	8
Pulse Counters	2
Communication Ports	RS-232
Operating Temperature	-25°C to +50°C
Pulse Channels	4
