Campbell CR1000 User Manual

Appendix G. Supporting Products Lists
G.3.4 Vibrating-Wire Input Modules List
Vibrating-wire input modules improve the measurement of vibrating wire sensors.
Table 198. Vibrating-Wire Input Modules
Model Description
CDM-VW300
Two-channel dynamic VSPECT vibrating-wire
measurement device
CDM-VW305
Eight-channel dynamic VSPECT vibrating-wire
measurement device
AVW200 Series
Two-channel static VSPECT vibrating-wire measurement
device
G.3.5 Passive Signal Conditioners Lists
Signal conditioners modify the output of a sensor to be compatible with the
CR1000.
G.3.5.1 Resistive-Bridge TIM Modules List
Table 199. Resistive Bridge TIM
1
Modules
Model Description
4WFBS120 120 Ω, four-wire, full-bridge TIM module
4WFBS350 350 Ω, four-wire, full-bridge TIM module
4WFBS1K 1 kΩ, four-wire, full-bridge TIM module
3WHB10K 10 kΩ, three-wire, half-bridge TIM module
4WHB10K 10 kΩ, four-wire, half-bridge TIM module
4WPB100 100 Ω, four-wire, PRT-bridge TIM module
4WPB1K 1 kΩ, four-wire, PRT-bridge TIM module
1
Teriminal Input Module
G.3.5.2 Voltage-Divider Modules List
Table 200. Voltage Divider Modules
Model Description
VDIV10:1 10:1 voltage divider
VDIV2:1 2:1 voltage divider
CVD20 Six-channel 20:1 voltage divider
G.3.5.3 Current-Shunt Modules List
Table 201. Current-Shunt Modules
Model Description
CURS100 100 ohm current-shunt module
647

Campbell CR1000 Specifications

General

Power Requirements	9.6 to 16 VDC
Data Logger Operating System	CRBasic
Memory	4 MB
Analog Inputs	16 single-ended or 8 differential
Analog Input Resolution	13 bits
Analog Input Range	+/-2.5V
Digital I/O	8
Pulse Counters	2
Communication Ports	RS-232
Operating Temperature	-25°C to +50°C
Pulse Channels	4
