Appendix B. Status, Settings, and Data Table Information (Status/Settings/DTI)
CPUDriveFree
Keyboard: Settings (General) ≈ line 16
CRBasic: variable = settings.keyword;
SetSettings()
Bytes remaining on the CPU: drive. This drive
resides in the serial FLASH and is always present.
CRBasic programs are normally stored here.
read-only
integer
2
Order and definitions of auto-calibration array elements:
(1) 5000 mV range 250 ms integration
(2) 2500 mV range 250 ms integration
(3) 250 mV range 250 ms integration
(4) 25 mV range 250 ms integration
(5) 7.5 mV range 250 ms integration
(6) 2.5 mV range 250 ms integration
(7) 5000 mV range 60 Hz integration
(8) 2500 mV range 60 Hz integration
(9) 250 mV range 60 Hz integration
(10) 25 mV range 60 Hz integration
(11) 7.5 mV range 60 Hz integration
(12) 2.5 mV range 60 Hz integration
(13) 5000 mV range 50 Hz integration
(14) 2500 mV range 50 Hz integration
(15) 250 mV range 50 Hz integration
(16) 25 mV range 50 Hz integration
(17) 7.5 mV range 50 Hz integration
(18) 2.5 mV range 50 Hz integration
3
In general, CommActive is set to TRUE when receiving incoming characters, independent of the protocol. It is set to FALSE
after a 40 second timeout during which no incoming characters are processed, or when the protocol is PakBus and the serial packet
protocol on the COM port specifies off line. Note, therefore, that for protocols other than PakBus that are serviced by the
SerialIO() instruction (ModBus, DNP3, generic protocols), CommActive will remain TRUE as long as characters are received at a
rate faster than every 40 seconds. In addition, PPP will activate its COM port with a 31 minute timeout. When PPP closes, it will
cancel the timeout and set CommActive as FALSE. Further, if there is a dialing process going on, CommActive is set to TRUE.
One other event that causes ComME to be active is the GOES instruction. In conclusion, the name CommActive can be
misleading. For example, if there are no incoming characters to activate the 40-second timeout during which time CommActive is
set to TRUE and only outputs data, then CommActive is not set to TRUE. For protocols other than PakBus,the active TRUE
lingers for 40 seconds after the last incoming characters are processed. For PPP, the COM port is always TRUE so long as PPP is
open.
Table 171. Status/Settings/DTI: D
Keyword
Alias,
Access,
Description
Read/Write,
DataType,
Units
Default
Value
Normal
Range
DataFillDays()
Keyboard: DataTableInfo ≈ line 5
CRBasic: variable = status.keyword
Reports the time required to fill a data table. Each
table has its own entry in a two-dimensional array.
First dimension is for on-board memory. Second
dimension is for CF-card memory.
read only
LONG array
days
DataRecordSize()
Keyboard: DataTableInfo: ≈3
CRBasic: variable = status.keyword
Reports the number of records in a data table.
read only
LONG array
DataTableName()
Keyboard: DataTableInfo ≈ line 1
CRBasic: variable = status.keyword
Reports the names of data tables. Array elements are
in the order the data tables are declared in the
CRBasic program.
read only
STRING
array
DeleteCardFilesOnMis
match
Keyboard: Settings (General) ≈ line 23
Settings Editor: Delete Cardout Data Files if
CardOut Data Table Mismatch
CRBasic: variable = settings.keyword;
SetSettings()
read/write
BOOLEAN
False
True or False
DNS()
Settings Editor name: Name Servers
Keyboard: Settings (TCP/IP) ≈ line 32
CRBasic: variable = settings.keyword;
SetSettings()
read/write
STRING
0.0.0.0
0–255.0
255.0255.0-
255
615
