Section 4. System Quickstart
o Modbus
o DNP3
o RS-485
Refer to the appendix Sensors — Lists
(p. 649) for a list of specific sensors available
from Campbell Scientific. A library of sensor manuals and application notes are
available at www.campbellsci.com to assist in measuring many sensor types. The
previous list of supported sensors is not necessarily comprehensive. Consult with
a Campbell Scientific application engineer for assistance in measuring unfamiliar
sensors.
4.3 Datalogger — Quickstart
Related Topics:
• Datalogger — Quickstart (p. 43)
• Datalogger — Overview
(p. 75)
• Dataloggers — List
(p. 645)
The CR1000 can measure almost any sensor with an electrical response. The
CR1000 measures electrical signals and converts the measurement to engineering
units, performs calculations and reduces data to statistical values. Most
applications do not require that every measurement be stored but rather combined
with other measurements in statistical or computational summaries. The CR1000
will store data in memory to await transfer to the PC with an external storage
devices or telecommunications.
CR1000 electronics are protected in a sealed stainless steel shell. This design
makes the CR1000 economical, small, and very rugged.
4.3.1.1 Wiring Panel — Quickstart
Related Topics
• Wiring Panel — Quickstart (p. 43)
• Wiring Panel — Overview
(p. 76)
• Measurement and Control Peripherals
(p. 366)
As shown in figure Wiring Panel (p. 44), the CR1000 wiring panel provides
terminals for connecting sensors, power, and communication devices. Surge
protection is incorporated internally in most wiring panel connectors.
43
