Campbell CR1000 User Manual

Section 8. Operation
Table 75. Calibrate() Instruction Results
Array
Cal()
Element
Descriptions of Array Elements
Typical Value
Differential (Diff)
Single-Ended (SE)
Offset or Gain
±mV Input
Range
Integration
10 SE Offset 25 250 ms ±5 LSB
11 Diff Offset 25 250 ms ±5 LSB
12 Gain 25 250 ms –0.0067 mV/LSB
13 SE Offset 7.5 250 ms ±10 LSB
14 Diff Offset 7.5 250 ms ±10 LSB
15 Gain 7.5 250 ms –0.002 mV/LSB
16 SE Offset 2.5 250 ms ±20 LSB
17 Diff Offset 2.5 250 ms ±20 LSB
18 Gain 2.5 250 ms –0.00067 mV/LSB
19 SE Offset 5000 60 Hz Rejection ±5 LSB
20 Diff Offset 5000 60 Hz Rejection ±5 LSB
21 Gain 5000 60 Hz Rejection –0.67 mV/LSB
22 SE Offset 2500 60 Hz Rejection ±5 LSB
23 Diff Offset 2500 60 Hz Rejection ±5 LSB
24 Gain 2500 60 Hz Rejection –0.34 mV/LSB
25 SE Offset 250 60 Hz Rejection ±5 LSB
26 Diff Offset 250 60 Hz Rejection ±5 LSB
27 Gain 250 60 Hz Rejection –0.067 mV/LSB
28 SE Offset 25 60 Hz Rejection ±5 LSB
29 Diff Offset 25 60 Hz Rejection ±5 LSB
30 Gain 25 60 Hz Rejection –0.0067 mV/LSB
31 SE Offset 7.5 60 Hz Rejection ±10 LSB
32 Diff Offset 7.5 60 Hz Rejection ±10 LSB
33 Gain 7.5 60 Hz Rejection –0.002 mV/LSB
34 SE Offset 2.5 60 Hz Rejection ±20 LSB
35 Diff Offset 2.5 60 Hz Rejection ±20 LSB
36 Gain 2.5 60 Hz Rejection –0.00067 mV/LSB
37 SE Offset 5000 50 Hz Rejection ±5 LSB
38 Diff Offset 5000 50 Hz Rejection ±5 LSB
39 Gain 5000 50 Hz Rejection –0.67 mV/LSB
40 SE Offset 2500 50 Hz Rejection ±5 LSB
41 Diff Offset 2500 50 Hz Rejection ±5 LSB
42 Gain 2500 50 Hz Rejection –0.34 mV/LSB
43 SE Offset 250 50 Hz Rejection ±5 LSB
348

Campbell CR1000 Specifications

General

Power Requirements	9.6 to 16 VDC
Data Logger Operating System	CRBasic
Memory	4 MB
Analog Inputs	16 single-ended or 8 differential
Analog Input Resolution	13 bits
Analog Input Range	+/-2.5V
Digital I/O	8
Pulse Counters	2
Communication Ports	RS-232
Operating Temperature	-25°C to +50°C
Pulse Channels	4
