Appendix B. Status, Settings, and Data Table Information (Status/Settings/DTI)
CalGain()
2
Keyboard: Status Table ≈ line 61
CRBasic: variable = status.keyword
Array of 18 floating-point values reporting
calibration gain for each integration / range
combination. Updated by background calibration.
read-only
IEEE4
mV
CalSeOffSet()
2
Keyboard: Status Table ≈ line 62
CRBasic: variable = status.keyword
Array of 18 integers reporting single-ended offsets
for each integration / range combination. Updated
by the auto (background) calibration when required.
read only
LONG
mV
near 0
CardBytesFree
Keyboard: Status Table ≈ line 18
CRBasic: variable = settings.keyword;
SetSettings()
Number of bytes free on the removable memory
card.
read only
LONG
-1 (no card)
>0
-1 (no card)
CardStatus
Station Status: Card Status
Keyboard: Status Table ≈ line 37
CRBasic: variable = status.keyword
Contains a string with the most recent status
information for the removable memory card.
Messages are self-defining, such as Card OK, No
Card Present, Card Not Being Used
read only
STRING
CentralRouters()
Settings Editor: Central Routers
Keyboard: Settings (General) ≈ line 13
CRBasic: variable = settings.keyword;
SetSettings()
Array of eight PakBus addresses for routers that can
act as central routers. By specifying a non-empty list
for this setting, the CR1000 is configured as a branch
router meaning that it will not be required to keep
track of neighbors of any routers except those in its
own branch. So configured, the CR1000 ignores any
neighbor lists received from addresses in the central
routers setting and forwards messages that it receives
to the nearest default router if it does not have the
destination address for those messages in its routing
table. Each entry must be formatted with a comma
separating individual values.
read/write
LONG
0
CommActive()
3
CRBasic: variable = status.keyword
"Hidden" array indicating if communications are
currently active on the corresponding ports. Order of
array elements is ComRS232, ComME, ComSDC7,
ComSDC8, ComSDC10, ComSDC11, Com1, Com2,
Com3, Com4
read only
BOOLEAN
False (except
for the active
communicati
on port)
True or False
CommConfig()
CRBasic: variable = status.keyword; SerialOpen()
"Hidden" array indicating configuration of
corresponding ports. When SerialOpen() is used,
values indicate format parameters for that
instruction. PakBus communications can occur
concurrently on the same port if the port was
previously opened (in the case of the CP UARTS)
for PakBus, or if the port is always open (CS I/O and
RS-232) for PakBus, the code is 4.
Order of array elements is RS-232, CS I/O ME,
COM310, CS I/O SDC7, CS I/O SDC8, CS I/O
SDC10, CS I/O SDC11, Com1, Com2, Com3, Com4
read/write
LONG
RS-232 is
always
hardware
enabled
RS-232
through
SDC8 = 4
(enabled)
COM1,
COM2,
COM3, or
COM4 = 0
0 = Program
disabled
4 = Program
enabled
613
