7. Push the Cutter Unit Detachment Lever to the left to unlock it.
8. Holding the Cutter Unit by the Lock Lever (a) and grip (b), remove it from the Carriage.
Important
• Never touch any part of the Cutter Unit except the Lock Lever (a) and grip (b). This may stain your
hands or cause injury. Additionally, this may damage the printer.
Caution
• Dispose of the used Cutter Unit in accordance with local regulations.
• Do not disassemble the Cutter Unit. Touching the blade may cause injury.
9. Holding the new Cutter Unit by the Lock Lever (a) and grip (b), insert it on the Carriage until it clicks into place (c).
Important
• After installing the Cutter Unit, hold it only by the grip (b) and pull the Cutter Unit forward to make
sure it does not come off. It may damage the printer if the Cutter Unit comes off.
Maintenance
>
Cutter Unit
>
iPF8300 Replacing the Cutter Unit
11
