4. Holding the Roll Holder so that the side with the white gear faces the side of the Roll Holder Slot with a white gear,
load the Roll Holder shaft (a) into the grooves (b) on both ends of the Roll Holder Slot, fully into the slot.
Caution
• Be careful not to drop the roll and hurt yourself when loading it.
• Be careful not to pinch your fingers between the Roll Holder shaft (a) and the guide grooves (b) when
loading rolls.
Handling Paper
>
Handling rolls
>
iPF8300 Loading Rolls in the Printer
7
779
