221Service Manual – CS7010™ 30 - Solution System
The bottom center Solution Tank Mounting
Screw is located underneath the machine by the
right-hand side squeegee assembly.
The bottom front Solution Tank Mounting Screw
is located underneath the machine by the main
broom actuator and scrub deck actuator.
13. Remove the solution tank from the machine.
14. Reinstall the solution tank by following the above steps in reverse order.
Solution Tank
Mounting Screw
Solution Tank
Mounting Screw
To Next Page
