Danfoss VLT series Programming Guide

6.5.4.14 MC_ReadDigitalInput_ISD51x
This function block provides the value of the specied
input. It is not guaranteed that pulses shorter than the
eldbus cycle time on the digital signal can be seen on the
function block.
The output data is available immediately.
MC_ReadDigitalInput_ISD51x
Input
EnableBOOL
InputNumberINT
AXIS_REF_-
ISD51x
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
BOOL
Value
Error
130BE295.10
Illustration 6.37 MC_ReadDigitalInput_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Input AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Get the value of the
selected input signal
continuously while
enabled.
InputNumber INT 1 Selects the input. Value
range: 1;2
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Value BOOL The value of the selected
input signal
Table 6.15 MC_ReadDigitalInput_ISD51x
6.5.4.15 DD_ReadAnalogInput_ISD51x
This function block reads the value of the analog input.
The output data needs to be read from the device and is
therefore not immediately available.
DD_ReadAnalogInput_ISD51x
Input
EnableBOOL
AXIS_REF_-
ISD51x
InputNumberINT
BOOLValid
BOOLBusy
DD_ERROR_ISD51xErrorInfo
BOOL
DWORDAbortCode
REALValue
Error
130BE267.10
Illustration 6.38 DD_ReadAnalogInput_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Input AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Get the value of the
selected input signal
continuously while
enabled.
InputNumber INT 1 Selects the input. Value
range: 1;2
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Value REAL The value of the selected
input signal
AbortCode DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
Table 6.16 DD_ReadAnalogInput_ISD51x
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 185
