6.5.4.16 MC_ReadDigitalOutput_ISD51x
This function block provides the value of the digital
output. It is not guaranteed that short pulses on the digital
signal can be seen on the function block.
The output data is available immediately.
MC_ReadDigitalOutput_ISD51x
Output
EnableBOOL
AXIS_REF_-
ISD51x
BOOLValid
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
BOOL
Value
Error
130BE296.10
Illustration 6.39 MC_ReadDigitalOutput_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Output AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Get the value of the
output signal continuously
while enabled.
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Value BOOL The value of the output
signal.
Table 6.17 MC_ReadDigitalOutput_ISD51x
6.5.4.17 DD_WriteDigitalOutput_ISD51x
This function block writes a value to the digital output of
the axis. If Enable is TRUE, the input Value is evaluated. If
the input Enable is FALSE, the last value is used. This
function block only works if the usage of the digital output
is congured accordingly (see chapter 7.21.5 Parameter
52-05: Digital Output Conguration (0x2FFF)).
DD_WriteDigitalOutput_ISD51x
Output
EnableBOOL
AXIS_REF_-
ISD51x
BOOLValid
BOOLBusyValueBOOL
DD_ERROR_-
ISD51x
ErrorInfo
BOOLError
130BE275.10
Illustration 6.40 DD_WriteDigitalOutput_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Output AXIS_REF_ISD51x Reference to the axis/
signal output.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Write the value of the
digital output.
Value BOOL FALSE Value of the output:
TRUE = set
FALSE = clear
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
Table 6.18 DD_WriteDigitalOutput_ISD51x
