Danfoss VLT series Programming Guide

6.5.4.19 DD_ReadParameter4_ISD51x
This function block asynchronously reads general objects
of up to 4 bytes from the object dictionary of the axis if
the Enable input is set. For the index and sub-index of the
parameters, see chapter 7 Servo Drive Parameter Description.
The output data is read from the device and is therefore
not immediately available.
DD_ReadParameter4_ISD51x
Axis
EnableBOOL
AXIS_REF_-
ISD51x
IndexUINT
Subindex
USINT
BOOLValid
BOOLBusy
DD_ERROR_ISD51xErrorInfo
BOOL
DWORDAbortCode
DWORDValue
Error
130BE270.10
Illustration 6.43 DD_ReadParameter4_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Axis AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Get the value of the
parameter continuously
while enabled.
Index UINT 0 Index of the object to be
read.
Subindex USINT 0 Sub-index of the object to
be read.
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
Value DWORD Value of the specied
parameter.
Table 6.21 DD_ReadParameter4_ISD51x
Programming
VLT
®
Integrated Servo Drive ISD
®
510 System
188 Danfoss A/S © 01/2017 All rights reserved. MG36D102
