6.5.4.20 DD_ReadParameter_ISD51x
This function block asynchronously reads general objects
from the object dictionary of the axis if the Enable input is
set. For the index and sub-index of the parameters, see
chapter 7 Servo Drive Parameter Description.
The output data is read from the device and is therefore
not immediately available.
DD_ReadParameter_ISD51x
Axis
EnableBOOL
AXIS_REF_-
ISD51x
IndexUINT
Subindex
USINT
pBuerUDINT
BuerSizeUDINT
BOOLValid
BOOLBusy
DD_ERROR_-
ISD51x
ErrorInfo
BOOL
DWORDAbortCode
UDINTDataLength
Error
130BE269.10
Illustration 6.44 DD_ReadParameter_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Axis AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Enable BOOL FALSE Get the value of the
parameter continuously
while enabled.
Index UINT 0 Index of the object to be
read.
Subindex USINT 0 Sub-index of the object to
be read.
pBuer UDINT 0 Pointer to a buer where
the read data will be
placed (use ADR()
function).
BuerSize UDINT 0 Maximum size of the read
data (size of the provided
buer given in byte; use
SIZEOF() function)
VAR_OUTPUT
Valid BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
Variable
name
Data
type
Default
value
Description
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
DataLength UDINT Length of the read data
[Byte].
Table 6.22 DD_ReadParameter_ISD51x
6.5.4.21 MC_WriteParameter_ISD51x
This function block modies the value of the specied
parameter.
It can take some time to write the data to the axis.
MC_WriteParameter_ISD51x
Axis
ExecuteBOOL
ParameterNumberINT
ValueDWORD
AXIS_REF_-
ISD51x
BOOLDone
BOOLBusy
BOOL
DD_ERROR_ISD51x
ErrorInfo
DWORD
AbortCode
Error
130BE304.10
Illustration 6.45 MC_WriteParameter_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Axis AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Write the value of the
parameter at rising edge.
Parameter-
Number
INT 0 Number of the parameter.
See Table 6.20. All other
numbers are not allowed
and lead to an error.
Value DWORD 0 New value of the specied
parameter.
VAR_OUTPUT
Done BOOL The function block has a
valid output.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Programming Programming Guide
MG36D102 Danfoss A/S © 01/2017 All rights reserved. 189
