Danfoss VLT series Programming Guide

Variable
name
Data
type
Default
value
Description
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
Table 6.23 MC_WriteParameter_ISD51x
6.5.4.22 DD_WriteParameter_ISD51x
This function block asynchronously writes general objects
to the object dictionary of the axis. For the index and sub-
index of the parameters, see chapter 7 Servo Drive
Parameter Description.
The data is written to the device asynchronously and is
therefore not immediately available in the axis.
DD_WriteParameter_ISD51x
Axis
ExecuteBOOL
AXIS_REF_-
ISD51x
BOOLDone
BOOLBusy
D_ERROR_ISD51xErrorInfo
BOOL
DWORDAbortCode
Error
IndexUINT
LengthUSINT
Subindex
pBuerUDINT
USINT
130BE276.10
Illustration 6.46 DD_WriteParameter_ISD51x
Variable
name
Data
type
Default
value
Description
VAR_IN_OUT
Axis AXIS_REF_ISD51x Reference to the axis.
See
chapter 6.5.4.1 AXIS_REF_IS
D51x.
VAR_INPUT
Execute BOOL FALSE Write the value of the
parameter at rising edge.
Index UINT 0 Index of the object to be
written.
Subindex USINT 0 Sub-index of the object to
be written.
Length USINT 0 Length of the data to be
written [Byte].
pBuer UDINT 0 Pointer to the buer that
contains the data to be
written (use ADR()
function).
VAR_OUTPUT
Done BOOL The value has successfully
been written to the
device.
Busy BOOL The function block is not
nished and new output
values are to be expected.
Error BOOL An error has occurred
within the function block.
ErrorInfo DD_ERROR_ISD51x Error identication and
instance identier.
See chapter 6.5.2.3 Error
Indication.
AbortCode DWORD SDO abort code if there is
an error. Available in the
list of constants:
SdoAbortCodes.
Table 6.24 DD_WriteParameter_ISD51x
6.5.4.23 DD_WriteParameter4_ISD51x
This function block asynchronously writes general objects
of up to 4 bytes to the object dictionary of the axis. For
the index and sub-index of the parameters, see
chapter 7 Servo Drive Parameter Description.
The data is written to the device asynchronously and is
therefore not immediately available in the axis.
Programming
VLT
®
Integrated Servo Drive ISD
®
510 System
190 Danfoss A/S © 01/2017 All rights reserved. MG36D102
6
6
