FOR-A FA-9600 Series User Manual

195
Category
Target
Item
Default
Value
Description
Required
Ref.
YPbPr Clip
FS1/FS2
YPbPr Clip Enable
0
0
1
0: Disable
1: Enable
5-12
White Clip
1090
500 - 1090
Setting value is one-tenth of input value.
Ex) 565 => 56.5%
Black Clip
-75
-75 - 500
Chroma Clip
1110
500 - 1130
Sync
FS1/FS2
Input Source
0/1
0
1
2
5
6
7
8
0: IN 1
1: IN 2
2: HDMI IN
(W/ FA-96EX3G44-R)
5-8: EX3G IN1-4
(W/ FA-96SFPC4)
5-6: SFP RX1-2
7-8: SFP TX1-2
(FA-96
EX3G44-R)
(FA-96
SFPC4)
5-13
Loss Mode
0/2
0
1
2
8
9
10
11
0: Color(Link) (W/ FA-964K)
1: Color(Sep) (W/ FA-964K)
2: Color
8: Auto Freeze
9: SDI Output Mute
10: SDI Output Mute(Link) (W/ FA-964K)
11: SDI Output Mute(Sep) (W/ FA-964K)
(FA-964K)
Input Loss Color
0
0
1
2
3
4
5
6
0: Black
1: Blue
2: Red
3: Magenta
4: Green
5: Cyan
6: Yellow
Color Processor Source
0/2
0
1
2
3
0: Synchronizer 1
1: Converter 1
2: Synchronizer 2
3: Converter 2
5-15
Sync Format
0
0
1
0: Auto (FS input signal format)
1: Manual (Format set below)
5-39
Format Standard
2
0
1
2
3
0: SD
1: 720
2: 1080
3: 2160 (FS 1 only, w/ FA-964K)
(FA-964K)
Format H Size
0
0
(Setting disabled)
Format Frame/Field Rate
11
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
0: 60p
1: 59.94p
2: 50p
3: 48p
4: 47.95p
5: 30p
6: 29.97p
7: 25p
8: 24p
9: 23.98p
10: 60i
11: 59.94i
12: 50i
13: 24PsF
14: 23.98PsF
15: 30PsF
16: 29.97PsF
17: 25PsF
Format Level
0
0
1
2
0: Follow Input
1: Level A
2: Level B(Dual Link)
Format Division
0
0
1
2
(FS1 only)
0: Follow Input
1: SQD
2: 2SI
FA-964K
Freeze Mode
0
0
1
2
0: Frame
1: Odd
2: Even
Sync Mode
0
0
1
2
3
0: Frame
1: Line
2: AVDL
3: Line(Min)
5-40
Sync H Phase
0
-2750 - 2750
-2750Clock - 2750 Clock
Sync V Phase
0
-563 - 563
-563Line - 563Line
Frame Delay
0
0 - 80
0: Disable
5-80: 0.5 to 8.0 Frames (for Normal Mode)
(in 5 increments)
5-42
