FOR-A FA-9600 Series User Manual

196
Category
Target
Item
Default
Value
Description
Required
Ref.
Ancillary
FS1/FS2
H ANC MUX Mode
0
0
1
2
0: Overwrite
1: Pass
2: Blank
5-29
H ANC PayloadId
0
0
1
0: Pass
1: Overwrite
5-30
H ANC VPID DR/CS Mode
0
0
1
0: Auto
1: Manual
H ANC VPID Color Space
0
0
1
2
3
0: Rec.709
1: VANC
2: UHDTV
3: Unknown
H ANC VPID Dynamic Range
0
0
1
2
3
0: SDR
1: HLG
2: PQ
3: Unspecified
H ANC VPID HD Mode
1
0
1
0: Disable
1: Enable
H ANC LTC OUT
0
0
1
0: Disable
1: Enable
5-32
H ANC VITC OUT
H ANC DVITC OUT
V ANC MUX Mode
1
1
2
1: Pass
2: Rewrite
5-29
V ANC User Packet Detect
DID
50
50-5F
User packet DID value (Support planned)
5-36
V ANC User Packet Detect
SDID
01
01-FF
User packet SDID value (Support planned)
V ANC ARIB B37 OUT
0
0
1
0: Disable
1: Through
5-37
V ANC ARIB B39 OUT
0
0
1
2
0: Disable
1: Through
2: Overwrite
V ANC User Packet Insert
0
0
1
0: Disable
1: Through (Support planned)
V ANC User Packet Insert
Line 525
12
8 - 41
Line number into which the user packet is
inserted for each video format.
(Support planned)
5-38
V ANC User Packet Insert
Line 625
8
V ANC User Packet Insert
Line 720
9
V ANC User Packet Insert
Line 1080i
9
V ANC User Packet Insert
Line 1080p(1.5G)
9
V ANC User Packet Insert
Line 1080p(3G-A)
9
V ANC User Packet Insert
Line 1080p(3G-B)
9
