FOR-A FA-9600 Series User Manual

197
Category
Target
Item
Default
Value
Description
Required
Ref.
V ANC ARIB B39 AUDIO
MODE
0
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
Unused
M
2M(D)
3M(D+M)
4M(2D)
5M(2D+M)
6M(3D)
7M(3D+M)
8M(4D)
S
2S
3S
4S
3/0
2/1
3/1
2/2
3/2
3/2+LFE(5.1)
S+M
S+2M(S+D)
5.1+S
3/1+S
3/2+S
9M Over(M Only)
5S Over(S Only)
Other
5.1+2S
5.1+3S
5.1+5.1
5.1+5.1+S
5.1+5.1+2S
7.1
7.1+S
7.1+2S
7.1+3S
7.1+5.1
7.1+5.1+S
7.1+5.1+2S
7.1+5.1+5.1
7.1+5.1+5.1+S
22.2
22.2+S
22.2+2S
22.2+3S
22.2+5.1
22.2+5.1+S
6-4
V ANC ARIB B39 AUDIO
MODE Enable
0
0
1
0: Pass
1: Overwrite
LTC Source
0
0
1
2
3
4
0: ST12M-2 ATC(LTC)
1: ST12M-2 ATC(VITC)
2: ST12M-1 VITC(DVITC)
3: ST12M-1 LTC IN (W/ FA-96DIN4-CBL)
4: Generator
(FA-96
DIN4-CBL)
5-33
LTC Loss Mode
0
0
1
2
0: Stay
1: Continue
2: Disable
LTC Generate Run
0
0
1
0: Stop
1: Start
LTC Frame Adjust
0
-16 - 16
LTC DropFrame
0
0
1
0: Off
1: On
LTC PresetTime HH
0
0 - 23
Preset LTC timecode
LTC PresetTime MM
0
0 - 59
LTC PresetTime SS
0
0 - 59
LTC PresetTime FF
0
0 - 29
VITC Source
1
0
1
2
3
4
0: ST12M-2 ATC(LTC)
1: ST12M-2 ATC(VITC)
2: ST12M-1 VITC(DVITC)
3: ST12M-1 LTC IN (W/ FA-96DIN4-CBL)
4: Generator
(FA-96
DIN4-CBL)
5-34
VITC Loss Mode
0
0
1
2
0: Stay
1: Continue
2: Disable
VITC Generate Run
0
0
1
0: Stop
1: Start
VITC Frame Adjust
0
-16 - 16
VITC DropFrame
0
0
1
0: Off
1: On
VITC PresetTime HH
0
0 - 23
Preset VITC timecode
VITC PresetTime MM
0
0 - 59
