FOR-A FA-9600 Series User Manual

198
Category
Target
Item
Default
Value
Description
Required
Ref.
VITC PresetTime SS
0
0 - 59
VITC PresetTime FF
0
0 - 29
Video System
FS1/FS2
Test Signal
0
0
1
2
0: Disable
1: 100% Color Bar
2: 75% Color Bar
5-44
VSYS
Genlock Source
0
0
1
2
3
0: GENLOCK IN
1: FS1
2: FS2
3: Free Run
5-40
SDI1 Bypass
1
0
1
0: Bypass
1: Operate
5-43
SDI2 Bypass
OUT 1a/1b
0
0
1
2
3
0. Proc. 1 / SL (Proc.1)
1. Proc. 2 / SL (Proc.2)
2: DL L1/L2(Proc.1)
3. QL L1/L2(Proc.1)
5-19
OUT 2a/2b
1
0
1
2
3
0: Proc. 1 / SL (Proc.1)
1: Proc. 2 / SL (Proc.2)
2: DL L1/L2(Proc.1)
3: QL L3/L4(Proc.1)
UHD Input Link
0
0
1
2
0: Single Link
1: Dual Link
2: Quad Link (W/ FA-96EX3G44-R)
HDMI OUT
0
0
1
0: Proc.1
1: Proc.2
FA-96UDC
FS1/FS2
Converter1 Source
0
0
1
0: Synchronizer1
1: Synchronizer2
FA-96UDC
(FS1)
5-14
Format Converter
0
0
1
0: Follow Input
1: Manual
FA-96UDC
5-20
Format Standard
2
0
1
2
3
0: SD
1: 720
2: 1080
3: 2160 (FS1, w/ FA-964K)
Format H Size
0
0
(Setting disabled)
Format Frame/Field Rate
11
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
0: 60p
1: 59.94p
2: 50p
3: 48p
4: 47.95p
5: 30p
6: 29.97p
7: 25p
8: 24p
9: 23.98p
10: 60i
11: 59.94i
12: 50i
13: 24PsF
14: 23.98PsF
15: 30PsF
16: 29.97PsF
17: 25PsF
Format Level
1
1
2
1: Level-A
2: Level-B (Dual Link)
Format Division (FS1 only)
1
1
2
1: SQD
2: 2SI
FA-96UDC
FA-964K
Delay Mode
0
0
1
2
0: Frame
1: Minimum
2: Adjustable
FA-96UDC
5-21
Adjust Delay H
0
-2750 - 2750
-2750Clock - 2750Clock
Adjust Delay V
0
-563 - 563
-563Line - 563Line
Frame Delay
0
0 - 16
0: Disable
1-16: 0.5 to 8.0 Frames (for Legacy Mode)
(in 5 increments)
5-42
Motion Sense
0
0
1
2
3
0: Adaptive
1: Field
2: Frame(Odd 1st)
3: Frame(Even 1st)
5-23
Filter Setting HS Details
0
0
1
0: Disable
1: Enable
5-24
Advanced Antialias H Mode
0
0
1
0: Auto
1: Manual
5-25
