FOR-A FA-9600 Series User Manual

200
Category
Target
Item
Default
Value
Description
Required
Ref.
Audio Demux
DMX1/DMX2
Alignment
0
0
1
0: Disable
1: Enable
6-1
Audio Clock
0
0
1
2
0: Auto
1: Sync SDI
2: Audio Clock
Audio Multiplex
EMB1/EMB2
Group1 Enable
1
0
1
0: Disable
1: Enable
6-3
Group2 Enable
Group3 Enable
Group4 Enable
Group1 HD Clock
0
0
1
2
3
0: Auto
1: Reference
2: Input Ch X/X
(Group1 1/2, Group2 5/6, Group3 9/10, Group4
13/14)
3: Input Ch X/X
(Group1 3/4, Group2 7/8, Group3 11/12,
Group4 15/16)
6-2
Group2 HD Clock
Group3 HD Clock
Group4 HD Clock
Audio Polarity
EMB1/EMB2
Ch1
I
Ch16
0
0
1
0: Normal
1: Invert
6-5
AES
Ch1
I
Ch8
0
0
1
0: Normal
1: Invert
6-18
Audio Source Select V2
ASEL
Ch1-4
0
0 - 33
0: EMB1 Input Ch.1-4
1: EMB1 Input Ch.5-8
2: EMB1 Input Ch.9-12
3: EMB1 Input Ch.13-16
8: EMB2 Input Ch.1-4
9: EMB2 Input Ch.5-8
10: EMB2 Input Ch.9-12
11: EMB2 Input Ch.13-16
12: AES Input Ch.1-4
13: AES Input Ch.5-8
(W/ FA-96AES- UBL)
14: OP(AES) Input Ch.1-4
15: OP(AES) Input Ch.5-8
(W/ FA-96ANA-AUD)
16: OP(ANA:B) In Ch.1-4
(W/ FA-96MADI)
18: OP(MADI) In Ch.1-4
19: OP(MADI) In Ch.5-8
20: OP(MADI) In Ch.9-12
21: OP(MADI) In Ch.13-16
22: OP(MADI) In Ch.17-20
23: OP(MADI) In Ch.21-24
24: OP(MADI) In Ch.25-28
25: OP(MADI) In Ch.29-32
26: OP(MADI) In Ch.33-36
27: OP(MADI) In Ch.37-40
28: OP(MADI) In Ch.41-44
29: OP(MADI) In Ch.45-48
30: OP(MADI) In Ch.49-52
31: OP(MADI) In Ch.53-56
32: OP(MADI) In Ch.57-60
33: OP(MADI) In Ch.61-64
(FA-96
AES-UBLC)
(FA-96
AES-UBL)
(FA-96
ANA-AUD)
(FA-96
MADI)
6-6
Ch5-8
1
Ch9-12
2
Ch13-16
3
Ch17-20
8
0 – 33
(Excluding
AES inputs)
Ch21-24
9
Ch25-28
10
Ch29-32
11
