FOR-A FA-9600 Series User Manual

202
Category
Target
Item
Default
Value
Description
Required
Ref.
Audio MAP
EMB1/EMB2
Ch1
0/16
0 - 31
64
65
66
80
81
82
83
96
98
100
102
104
106
108
110
112
114
116
118
120
122
124
126
0 - 31: Source Ch.1 - 32
64: 500Hz Tone
65: 1kHz Tone
66: Silence
80: Downmix 1_L
81: Downmix 1_R
82: Downmix 2_L
83: Downmix 2_R
96: Mono Sum 1
98: Mono Sum 2
100: Mono Sum 3
102: Mono Sum 4
104: Mono Sum 5
106: Mono Sum 6
108: Mono Sum 7
110: Mono Sum 8
112: Mono Sum 9
114: Mono Sum 10
116: Mono Sum 11
118: Mono Sum 12
120: Mono Sum 13
122: Mono Sum 14
124: Mono Sum 15
126: Mono Sum 16
6-10
Ch2
1/17
Ch3
2/18
Ch4
3/19
Ch5
4/20
Ch6
5/21
Ch7
6/22
Ch8
7/23
Ch9
8/24
Ch10
9/25
Ch11
10/26
Ch12
11/27
Ch13
12/28
Ch14
13/29
Ch15
14/30
Ch16
15/31
AES
Ch1
0
(Same as
above)
See above.
6-12
Ch2
1
Ch3
2
Ch4
3
Ch5
4
Ch6
5
Ch7
6
Ch8
7
AES SET
SYS
Hysteresis Ch1/2
0
0
1
2
0: Disable
1: Group A
2: Group B
6-16
Hysteresis Ch3/4
0
Hysteresis Ch5/6
0
Hysteresis Ch7/8
0
Terminal I/O 1/2-3/4
0
0
1
0: Input
1: Output
6-17
Terminal I/O 5/6-7/8
0
Audio Gain
EMB1/EMB2
Master Gain
0
-200 - 200
Setting value is one-tenth of input value.
Ex) 123 => 12.3dB
6-19
Ch1
|
Ch16
0
-400 - 400
Setting value is one-tenth of input value.
Total gain for each channel =
(Master Gain value) + (Channel Gain value)
AES
Master Gain
0
-200 - 200
Setting value is one-tenth of input value.
Ex) 123 => 12.3dB
6-19
Gain Ch1
|
Gain Ch8
0
-400 - 400
Setting value is one-tenth of input value.
Total gain for each channel =
(Master Gain value) + (Channel Gain value)
Audio Delay
ADLY G1/ADLY G2
Master
1
1 - 1000
Master Delay
6-22
Ch1
|
Ch16
0
-999 - 999
Total delay for each channel =
(Master Delay value) + (Channel Delay value)
Delay Adj FS
0
0
1
0: FS1
1: FS2
6-23
Audio Dolby Alignment
AES
FS Select A
0
0
1
0: FS1
1: FS2
6-24
FS Select B
0
0
1
0: FS1
1: FS2
