FOR-A FA-9600 Series User Manual

203
Category
Target
Item
Default
Value
Description
Required
Ref.
CDLY
EMB1
1
0
1
0: Disable
1: Same as FS1/2
6-25
EMB2
AES
1
0
1
2
0: Disable
1: Same as FS1
2: Same as FS2
Audio System
ASYS
Reference Level
1
0
1
0: -18dBFS
1: -20dBFS
7-2
Grade
0
0
1
0: Professional
1: Consumer
Resolution
2
0
1
2
0: 16bit
1: 20bit
2: 24bit
Silence Time
2
1 - 10
1 - 10: 1 - 10sec
Digital SilenceLevel
4
0
1
2
3
4
0: -48dBFS
1: -54dBFS
2: -60dBFS
3: -66dBFS
4: -72dBFS
Error Sensing
1
0
1
2
0: Disable
1: Normal
2: Sensitive
Error Fade
0
0
1
0: Disable
1: Enable
Analog SilenceLevel
3
0
1
2
3
0: -48 dBFS
1: -54 dBFS
2: -60 dBFS
3: -66 dBFS
FA-96
ANA- AUD
6-28
Analog Silence Time
2
1 - 10
1 - 10: 1 - 10sec
Audio Test/Mute
Signal
EMB1 Test Signal
0
0
1
2
0: Off
1: 500Hz Tone
2: 1kHz Tone
7-3
EMB2 Test Signal
AES Test Signal
0
0
1
2
1: 500Hz Tone
2: 1kHz Tone
Master Mute
0
0
1
0: Disable
1: Enable
Audio HDMI
SYS
Group1
0/1
0
1
2
3
0: EMB.Group1(Ch.1-4)
1: EMB.Group2(Ch.5-8)
2: EMB.Group3(Ch.9-12)
3: EMB.Group4(Ch.13-16)
7-3
Group2
HDMI Out Enable
1
0
1
0: Disable
1: Enable
FA-96EX3G44
SlotA
OUT 1
|
OUT 4
0
0
1
2
3
0: Proc.1 / SL(Proc.1)
1: Proc.2 / SL(Proc.2)
2: DL(Proc.1)
3: QL(Proc.1)
FA-96
EX3G44-R
5-19
Bypass1
|
Bypass4
1
0
1
0: Bypass
1: Operate
5-43
FA-96EX12G06
SlotA
Simultaneous
4K/HD mode
OUT 1a/1b/2
0
0
1
2
3
0: SL (Proc.1)
1: SL (Proc.2)
2: DL L1/L1/L1 (Proc.1)
3: QL L1/L1/L2 (Proc.1)
FA-96
EX12G06
5-19
Simultaneous
4K/HD mode
OUT 3a/3b/4
1
0
1
2
3
0: SL (Proc.1)
1: SL (Proc.2)
2: DL L2/L2/L2 (Proc.1)
3: QL L3/L3/L4 (Proc.1)
Dual HD mode
OUT 1a/1b/2
0
0
1
0: Proc. 1
1: Proc. 2
OUT 3a/3b/4
3D-LU mode
OUT 1a/1b/2
0
0
2
3
0: SL (Proc.1)
2: DL L1 (Proc.1)
3: QL L1 (Proc.1)
OUT 3a/3b/4
