SECTION 7 - TECHNICAL SPECIFICATIONS
9
CURSOR SERIES
Print P4D32C006 E Base - 03/2015
Type
F3HFA615A*D001 F3HFA615B*D001
mm
X
Recessing
X
0.54- 0.86
X
1.47 - 1.79
Between valve seat and cylinder head
X
0.040 - 0.090
X
H
H1
H
Valve spring height:
free spring H 76
under a load of:
504 N/mm
2
H1 59
887 N/mm
2
H2 46



Camshaft bush housing fitted in the
cylinder head: 1  7
Ø 88.000- 88.030



1
2
3
Camshaft journals: 1  7 Ø 82.950 - 82.968

Camshaft bushing outer diameter: Ø 88.153 - 88.183

Bushing inner diameter Ø 83.018 - 83.085
Bushings and seats in cylinder head 0.103 - 0.163
Bushings and supporting pins 0.050 - 0.135
H
Useful cam height:
9.231
9.5607

1
Rocker-arm shaft Ø1 41.984 - 42.000

Internal rocker arm diameter:
42.045 - 42.061
59.000 - 59.019
