221066
Figure 28
Electric starter motor wiring diagrams
Electric start er motor ch aracteristics
18
SECTION 3 - ELECTRIC EQUIPMENT
CURSOR SERIES
Base - 03/2015 Print P4D32C006 E
Ref. Description Measurement unit
T
C
O
V
S
Torque
Current strength
Power
Voltage
Speed
Nm
A
KW
V
Rpm
