2. Replacement and adjustment of parts
27410
2/2
27410
Order sorter section
4. Press the manual sorter switch several times to check the stop position of the print receiving tray.
If the stop position is not stable, check the timing belt tension and the chain tension of the sorter motor and adjust them
properly.
NOTE
• Tension adjustment of the sorter motor timing belt
☞20120
• Adjustment of the chain tension
☞20120
Dimension A
Sorter home sensor holder
Top of receiving tray rail
Print receiving tray
G050751
