Error and attention message regulation
1/1
4. Troubleshooting
4002
4002
Suffix number
!
!!
! Types of suffix number
Suffix numbers can be classified to the following three types.
• No suffix numbers
• Displays the condition
• Displays the total of bit operation
!
!!
! No suffix numbers
If the occurring condition is single
Example 1
!
!!
! Displays the condition
If the occurring condition is multiple and only one of them is the object of the occurring cause, its suffix number appears in five digits.
Example 2
!
!!
! Displays the total of bit operation
If the occurring condition is multiple and some of them are possible to be the objects of the occurring cause at the same time, the total
of the target suffix numbers (bit) appears.
NOTE
• The bit operation value appears by decimal digit.
Example 3
NOTE
• If the sensors 1 and 3 of example 3 are the objects, 00005 is shown. If all the sensors are the objects, 00031 is shown.
Suffix number Condition
00000 The cover is opened.
Suffix number Condition
00001 The sensor does not detect DARK.
00002 The sensor does not detect LIGHT.
Suffix number (bit) Condition
00001 Sensor 1 does not detect.
00002 Sensor 2 does not detect.
00004 Sensor 3 does not detect.
00008 Sensor 4 does not detect.
00016 Sensor 5 does not detect.
