4. Troubleshooting
45500
3/14
45500
Error message: Processor 1
No. 05504
The processing solution temperature is below the processing range. P1
No. 05505
The processing solution temperature is below the processing range. P2
No. 05506
The processing solution temperature is below the processing range. P3
Alarm release
NO
Error message release
NO
NOTE
• The processing solution temperature will be adjusted when the error display is closed.
Condition
Check Point
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Error message No. Condition
No. 05504-0000 The P1 processing solution temperature falls below the processing range (setting temperature − 1°C) after
the temperature adjustment is finished. (P1 temperature sensor)
No. 05505-00000 The P2 processing solution temperature falls below the processing range (setting temperature − 3°C) after
the temperature adjustment is finished. (P2 temperature sensor)
No. 05506-00000 The PS processing solution temperature falls below the processing range (setting temperature − 5°C) after
the temperature adjustment is finished. (PS temperature sensor)
1 Confirm that the value measured via Thermosensor Calibration is correctly entered.
When temperature is incorrectly adjusted Manual No.
Processing solution heater ☞63290
Processor relay PCB ☞66220
Processor control PCB
☞66200
When temperature is incorrectly detected Manual No.
Thermosensor ☞63290
Processor control PCB
☞66200
