4. Troubleshooting
45600
45600
Error message: Tablet replenishment
No. 05612[J]
Tablet Replenishment Elevator operation error.
Error message release
NO
Condition
Diagnosis
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Even though a specified time has passed after the elevator moves up, the elevator lower sensor does not turn
LIGHT.
00002 When the elevator was raised, the elevator middle sensor did not turn DARK even though the elevator lower
sensor turned LIGHT and a specified time passed.
00003 When the elevator was raised, the elevator upper sensor did not turn DARK even though the elevator middle
sensor turned DARK and a specified time passed.
00004 Even though the elevator was lowered for a specified time, the elevator upper sensor did not turn LIGHT.
00005 When the elevator was lowered, the elevator middle sensor did not turn LIGHT even though it turned dark and a
specified time passed.
00006 When the elevator was lowered, the elevator lower sensor did not turn DARK even though the elevator middle
sensor turned LIGHT and a specified time passed.
Adjustment failure point Manual No.
Elevator sensor attached to inappropriate position ☞63310
Position adjustment failure of elevator lower sensor ☞ 27680
Position adjustment failure of elevator middle sensor
☞27670
Position adjustment failure of elevator upper sensor ☞ 27660
Failed part Manual No.
Confirm that the upper sensor for elevator is dirty.
☞63310
Upper sensor for elevator ☞63310
Elevator motor ☞63310
Tablet replenishment driver PCB
☞66500
Processor control PCB ☞66200
