4. Troubleshooting
45900
4/16
45900
Error message: F replenishment
No. 05905[F]
P1R replenishment solution output amount/replenishment solution level management
is abnormal.
No. 05906[F]
P2RA replenishment solution output amount/replenishment solution level management
is abnormal.
No. 05907[F]
P2RA replenishment solution output amount/replenishment solution level management
is abnormal.
Error message release
YES
IMPORTANT
• If the above error message is shown, do not click YES to close it and continue the printing process without performing the
diagnosis below.
After a set number of prints are output,
☞No. 05912[F] Predetermined process amount was exceeded. will be shown,
and then printing cannot be performed.
NOTE
• If printing process is continued after the above error is shown, the time is counted as Replenishment Lack Time and the P1R, P2RA
and P2RB replenishers will not be replenished.
Condition
Suffix number Condition
00001 When opening process is complete, # # # (upper) replenishment solution level sensors of each processing
solution do not turn off even a specified amount of processing solution is added.
00002 When # # # (upper) replenishment solution level sensors of each processing solution turned off, the processing
solution less than the specified amount was added and # # # (lower) replenishment solution level sensors of each
processing solution also turned off.
00003 After # # # (upper) replenishment solution level sensors turned off, # # # (lower) replenishment solution level
sensors of each processing solution do not turn off even though the processing solution exceeding the specified
amount has been added.
For details of operation specification, see ☞ 57010.
• For the QSS-3701/3702/3703/LP7500/LP7600, about 507 prints whose size is 127 mm × 89 mm can be processed after the error
occurs.
• For the QSS-3704/3705/LP7700/LP7900, about 545 prints whose size is 127 mm × 89 mm can be processed after the error occurs.
• If Pump Output Amount Measurement of Pump Output Amount Setting is not performed at system installation, the above
errors may occur.
• The causes are shown below.
1. Even if each replenishment pump operates for a specified time, lower amounts of solution than the specified range is
replenished, and # # # (lower) replenishment solution level sensor of each solution is off.
2. If each replenishment pump operates for a specified time, larger amount of solution than the specified range is replenished,
and # # # (lower) replenishment solution level sensor of each solution does not turn off.
• If the processor control PCB is replaced, data (all data, or only the processor data) is initialized
or
☞No. 05538 Backup data error. Processor occurs, suffix number 00002 of the error shown above may occur. ☞57020
Countermeasure
1. Check the status of the replenishment solution level sensors of each processing solution with Input Check.☞35220
2. Perform recovery procedure 2 from the replenishment error.☞4620
Distributed by: minilablaser.com
