4. Troubleshooting
46550
46550
Error message: Colorimeter
No. 06554
Calibration Plate advance error.
Error message release
YES
Condition
NOTE
• Refer to the colorimeter calibration operation flow. ☞56600
Check Point
Diagnosis
$ Symptoms due to connection failure of wiring/symptoms resulted from blowout of fuse
NOTE
• To access the wiring diagrams, click Wiring diagrams in Bookmarks.
Suffix number Condition
00001 Although the calibration plate has been fed for a specified length, paper sensor 2 dose not turn dark.
00002 When the calibration plate is being fed, paper sensor 1 turns LIGHT from DARK.
00003 In initial operation, although a specified length of moving to the home position was attempted to the calibration
plate, paper sensors 1 does not turn light.
00004 When the calibration plate is being fed, paper sensor 1 turns LIGHT.
00005 Not occur
00006 Although the calibration plate has been fed for a specified length, paper sensor 1 does not turn DARK.
1 If the errors of suffix number 00003 or 00006 occur with the calibration plate placed on the standby position, clean paper
sensor 1.
Failed part Manual No.
Paper sensor 1 or 2
☞63318
Calibration plate advance motor
Processor control PCB ☞66200
Processor I/O PCB 2
☞66211
Processor I/O PCB 1 ☞66210
Colorimeter unit ☞27460
Symptoms due to the wiring connection failure Symptoms of fuse blowout
−
☞4203 ☞4252
