5. Operation sequence
50500
2/2
50500
Starting up/Closing down Operation
9. If the colorimeter is attached, confirm the connection status between the processor control PCB and
colorimeter.
If there was a communication error between the processor control PCB and colorimeter.
• ☞No. 06903-00002
Serial communication error.
10. The laser control PCB checks conditions of the G laser driver and laser unit.
If the condition of G laser driver was abnormal
• ☞No. 06075 G Laser control error.
If the condition of the laser unit was abnormal
• ☞No. 06073 Synchronous Sensor error.
• ☞No. 06076 Polygon Mirror control error.
11. Controls the exposure engine.
The system starts adjusting the laser unit temperature.
• Temperature control started → Temperature control completed is displayed for Laser temperature control status of
Status Display.
12. When Laser temperature control status of Status Display turns Temperature control started →
Temperature control completed, the laser control PCB checks the light source state of the laser unit.
If the light source state of the laser unit was abnormal
• ☞No. 06106 G Laser light source status error.
13. The process for starting the Printer/Processor software completes.
14. The temperature adjustment of the processing solutions is completed.
15. Temperature adjustment of the laser unit is completed.
16. The system displays an attention/error message if any.
